ANX1122-EV

Analogix IC Part Number: ANX1122FN-AB

Description: Generic 2L DP to LVDS EVB

HDCP: No

ANX7428-EV

Analogix IC Part Number: ANX7428BN-AD

Description: 4L USB C Switch

HDCP: No

ANX7430-EV1

Analogix IC Part Number: ANX7430BN-CA

Description: 10G USB-C Re-Timer and Switch (USB3), BGA

HDCP: No

ANX7440-EV2

Analogix IC Part Number: ANX7440BN-CB

Description: 10G USB-C Re-Timer and Switch (DP/USB3), QFN

HDCP: No

ANX7447-RD1

Analogix IC Part Number: ANX7447QN-AC

Description: USB-C (DP/USB3) Mux Switch and PD 3.0 CTLR (1 USB-C port)

HDCP: No

ANX7447-RD2

Analogix IC Part Number: ANX7447QN-AC

Description: USB-C (DP/USB3) Mux Switch and PD 3.0 CTLR (2 USB-C ports)

HDCP: No

ANX7490-EV2

Analogix IC Part Number: ANX7490QN-CB

Description: 10G USB3 Re-Timer (USB Type-A), QFN

HDCP: No

ANX7496-EV2

Analogix IC Part Number: ANX7496QN-CB

Description: 8.1G DP Re-Timer (DP Type-A), QFN

HDCP: No

ANX7530-EV1

Analogix IC Part Number: ANX7530BH-AC

Description: ANX7530/7533 (DP to Dual MIPI)

HDCP: HDCP1.4 & 2.2

ANX7530-EV2

Analogix IC Part Number: ANX7530BH-AC

Description:  2 pcs ANX7530 (DP to Dual MIPI) + 2 pcs LCD Panel

HDCP: HDCP1.4 & 2.2

ANX7533-EV3

Analogix IC Part Number: ANX7530BH-AC

Description: 2 pcs ANX7533 (DP to Dual MIPI) + 2 pcs LCD Panel

HDCP: HDCP1.4 & 2.2

ANX7625-EV1

Analogix IC Part Number: ANX7625BH-AC
Description: HDMI 1.4 to USB-C Output (MIPI-DPI to USB-C)
HDCP: HDCP1.4 & 2.2

ANX7625-EV2

Analogix IC Part Number: ANX7625BH-AC
Description: HDMI 1.4 to USB-C Output (MIPI-DPI to USB-C)

HDCP:  HDCP1.4 & 2.2

ANX7688-EV

Analogix IC Part Number: ANX7688BH-AC

Description:HDMI 1.4/USB3.1 to Type-C AV (1080P60, HDCP2.0)

HDCP: HDCP1.4 & 2.2

ANX7737 + ANX7402-RD

Analogix IC Part Numbers: ANX7737FH-AC and ANX7402QN-AD
Description: USB C to HDMI Adapter, No Charging, ANX7402 PD
HDCP: HDCP1.4

ANX7737 + ANX9847 + ANX7402-RD

Analogix IC Part Numbers: ANX7737FH-AC, ANX7402QN-AD and ANX9847FN-AA
Description: USB-C to HDMI, VGA, USB3 outputs, ANX7402 PD

HDCP: HDCP1.4

ANX7737-EV

Analogix IC Part Number: ANX7737FH-AC
Description: DP to HDMI(2160p)

HDCP: HDCP1.4

ANX9833-RD

Analogix IC Part Number: ANX9833FN-AA
Description: 2L DP1.1 to VGA
HDCP: No

Contact Us

To order an Analogix eval board from BSC, please submit a request below.  Please include your name, email address and the eval board part number you are interested in procuring.
